HMI DockPanel

The DockPanel docks its child controls to one of the four sides Left, Top, Right or Bottom, where the respective child takes at much space as it needs.

At the bottom of the DockPanel node is a pin that allows it to connect several children.

Inputs

Style (Type: Style)

Optional styling of the DockPanel.

The DockPanel respects the Width, Height, HorizontalAlignment, VerticalAlignment, Margin and Background styles.

LastChildFill (Type: boolean)

If true, the last child added to the DockPanel takes all the available space. If false, the last child added takes only the space it needs.

Background (Type: SolidColorBrushByte)

The background of the DockPanel.

Comments

Children of the DockPanel have the attached property Dock. This property can take the values Left, Top, Right and Bottom and specifies to which side the child will be docked.

Example

Here is an example that docks a text label to the top and a webbrowser to the left, where the webbrowser fills the available space fully. This definition

creates the following user interface:
